Steeringwithjoystickcontrol
Themachinewilltravelinthedirectiontheleverismoved.
Whentheleverisreleased,itwillreturntotheneutral,
centerposition.Usecautionwhenturningthemachine,
asthemachinecanturnsharplyifthejoysticksteering
leverisusedabruptly.Whenexecutingaturn,movethe
levergraduallyinthedirectionofthedesiredturn.
Steeringcanbereturnedinstantlytostandardsteeringif
thesteeringwheelismovedfromitsstationaryposition.
RCIL10WHL204BAL13
Leftturn
Movethelevergraduallytotheleft.Anabruptmovement
totheleftwillcausethemachinetoturnsharplytotheleft.
Besuretomovetheleverinacareful,gradualshift.
Rightturn
Movethelevergraduallytotheright.Anabruptmovement
totherightwillcausethemachinetoturnsharplytothe
right.Besuretomovetheleverinacareful,gradualshift.
Reverseleft
Withthetransmissioninreverse,movethelevergradually
totheleftforaleftreverseturn.Anabruptmovementto
theleftreversewillcausethemachinetoturnsharplyto
theleft.Besuretomovetheleverinacareful,gradual
shift.
Reverseright
Withthetransmissioninreverse,movethelevergradually
totherightforarightreverseturn.Anabruptmovement
totherightreversewillcausethemachinetoturnsharply
totheright.Besuretomovetheleverinacareful,gradual
shift.
Steeringandbucket
Thesteeringspeedofthewheelloaderisthesameinboth
directionsandwillincreasegraduallywiththepositionof
thejoystick.
Theliftarmandbucketcontrolleverwilloperateasit
wouldwithconventionalsteering.Practicewiththejoy-
sticksteeringinaclearareaunobstructedbypeopleand
otherequipment.
