M-Series Operator’s Manual 4/9/2015 10-28
Depth: Total: Total depth of the circular pocket.
Depth: Per Pass: Depth of each individual pass.
Depth: Plunge Rate: Z-axis speed of descent.
Depth: Plunge Type: Straight or Ramped. Straight plunge does a vertical Z plunge with no X, Y movement. Ramped
plunge does a zigzag plunge limited by the Plunge Angle entered below.
Depth: Plunge Angle: The maximum limit angle allowed for a ramped plunge. A special value of 0 means that there
is no limit angle. Note: This field means nothing if the Plunge Type is Straight.
Rough Cuts: Selects type of rough cut: conventional or climb. Use F3 - Toggle or SPACE to toggle between them.
Rough Cuts: Stepover: Amount of material removed by cutter during each pass around the pocket.
Rough Cuts: Feedrate: Speed at which cutter performs rough cuts.
Finish Pass: Selects type of finish pass: climb, conventional or none at all. Use F3 - Toggle or SPACE to toggle.
Finish Pass: Amount: Amount of material to be removed on the finish pass.
Finish Pass: Feedrate: Speed at which cutter performs finish pass.
