M-Series Operator’s Manual 4/9/15
10-61
N0030 Circular pocket
Center: X :
0.0000
Y :
0.0000
Surface Height
:
0.0000
Diameter :
1.0000
Cleanout :
Yes
Depth: Total
:
0.5000 INC
Per Pass :
0.2500
Plunge Rate :
2.0000 [M]
Plunge Type :
Ramped
Plunge Angle :
0.00°
Rough Cuts :
Conventional
Stepover :
0.2250
Feedrate :
20.0000 [M]
Finish Pass :
Climb
Amount :
0.0020
Feedrate :
10.0000 [M]
F10 - Accept Keep selected values.
F5 - Cycles Access the list of available Canned Cycles.
F1 - Drill Select drilling cycles
F2 - Drill BHC Select the bolt hole circle type of drilling cycles
N0040 Drill bolt holes
Cycle Type :
Drilling
Center: X :
0.0000
Y :
0.0000
Surface Height :
0.0000
Clearance Height
:
0.2500
INC
'Rapid To' Depth :
0.1000
INC
Depth: Total
:
0.5000
INC
Plunge Rate :
2.0000
Dwell Time :
0.0000
Number of holes :
4
Radius :
1.2500
Start angle :
45.00°
F8 - Graph Display a preview of the part up to this point. This preview can
be used to detect problems that may occur if the part was cut now.
