M-Series Operator’s Manual 4/9/15
10-72
N0080 Rectangular pocket
Center: X
:
3.0000
Y
:
0.0000
Surface Height
:
0.0000
Length (X)
:
0.7500 INC
Width (Y)
:
0.4250 INC
Corner Radius
:
0.1875
Depth: Total
:
0.2500 INC
Per Pass
:
0.2500
Plunge Rate
:
2.0000
Plunge Type
:
Ramped
Plunge Angle
:
0.00
°
Rough Cuts :
Conventional
Stepover
:
0.1000
Feedrate
:
2.0000
Finish Pass :
None
Amount
:
0.0000
Feedrate
:
2.0000
F10 - Accept Keep selected values.
F1 - Rapid Move to a location outside the part. The purpose of this move is
to prepare to use cutter compensation on the tool.
N0009 Rapid traverse
End: X
:
5.0000
Y
:
0.5000
Z
:
0.1000
Angle :
14.0365°
Length
:
2.0615
F10 - Accept Keep selected values.
F2 - Linear Need to do a zero length move to move the cutter down to z-
depth before starting the lead in move to the part. Not including
the zero length move to z-depth would confuse cutter comp. and
cause the program to do weird things.
N0010 Linear Move
F10 - Accept Keep selected values.
End X
: 5.0000
Y
: 0.5000
Z
: -0.0500
Angle : 0.0000
Length : 0.0000
Connect Radius : 0.0000
Feedrate : 10.0000
To Next Page
