Centroid M400 - Page 156

M-Series Operator’s Manual 4/9/15
10-74
4.0000"
2.0000" 1.0000"
45º
0.7500" x 0.4250"
3.1500" R
1.2500" R
.1875
.9250
.6000
.6250
.3750
Arc
2
Arc
3
Arc
4
3.15” R
P2
P3
P4
P5
Arc1
Arc 5
FIG 3. - Tangent point and arc reference.
N0013 Arc
Arc type : EP&R
Mid X :
Y :
Z :
End: X : 4.6250
Y : 0.0000
Z : -0.0500
Center: X :
Y :
Z :
Angle :
Radius : .625
Plane : XY
Direction : CW
Connect Radius : 0.0000
Feedrate : 10.0000
Angle <= 180° : Yes
F6 - Math Help We are trying to find end points for the arcs that make up the
outside edge of the part. Note: the main Math Help menu will list
all available Math Help solvers.
P1
