M-Series Operator’s Manual 4/9/15 11-7
Index Description Returns R/W
23301-23308 min_error (PID) for axes 1-8 R
23401-23408 at_index_pulse for axes 1-8 R
23501-23508 travel_minus for axes 1-8 R/W
23601-23608 travel_plus for axes 1-8 R/W
23701-23708 axis_home_set for axes 1-8 R
23801-23808 abs_position (in encoder counts) for axes 1-8 R
23901-23908 PID_out for axes 1-8 R
24001-24008 reference set for axes 1-8 R
24101-24108 Axis reference value for axes 1-8 R
24201-24208 tilt table level offsets for axes 1-8 R
24301-24308 dsp positions for axes 1-8 R
24401-24408 abs_position (in encoder counts) for axes 1-8 R
24501-24508 dsp positon in local cooridinates for axes 1-8 R
24601-24608 local probing +limit position for axes 1-8 R
24701-24708 local probing -limit position for axes 1-8 R
24801-24808 probe stylus compensation amount for axes 1-8 R
24901-24908 servo controlled axis indicator for axes 1-8 0 = no, 1 = yes R
25000 DRO_display_units R
25001 default_units_of_measure R
25002 PLC_type R
25003 console_type R
25004 jog_panel_optional R
25005 min_spin_high R
25006 max_spin_high R
25007 home_at_powerup R
25008 screen_blank_time R
25009
Displayed / Calculated spindle speed. If parameter
78 =1 and spindle encoder is mounted.
R
25010 current spindle position (in counts) R
25011 dsp_time (in seconds) R
25012 time (in seconds) R
25013 clear max/min PID errors R
25014 software type (Mill/Lathe) R
25015 feedrate override R
25016 spindle override R
25017 OS Windows/LINUX = 2; other OS = 1.0
R
25018 CNC series number (11 for CNC11) R
25019 Software version number R
25020 Software Beta revision number R
25021 Digitizing boundary hit hit = 1, not hit = 0 R
25022 last M115/116/125/126 probe trip 1 = tripped, 0 = not tripped R
25023 Drive type 0 = Standard, 1 = Legacy DC,
2 = Legacy AC
R
25101-25108 Encoder counts away from index pulse for axes 1-8
Counts away from index pulse.
Values less than 0 means that index
pulse is not detected yet.
R
26001-26008 dsp mechanical machine positions for axes 1-8 R
26101-26108 dsp mechanical local positions for axes 1-8 R
26201-26208 local + travel limit position for axes 1-8 R
26301-26308 local - travel limit position for axes 1-8 R
26401-26404 Axis 1 reference points 1-4 R
26501-26504 Axis 2 reference points 1-4 R
26601-26604 Axis 3 reference points 1-4 R
26701-26704 Axis 4 reference points 1-4 R
26801-26804 Axis 5 reference points 1-4 R
26901-26904 Axis 6 reference points 1-4 R
27001-27004 Axis 7 reference points 1-4 R
27101-27104 Axis 8 reference points 1-4 R
