Centroid M400 - Page 183

M-Series Operator’s Manual 4/9/15
12
-
1
Chapter 12
CNC Program Codes: G-codes
G-code Group Description
G00 * A Rapid Positioning
G01 A Linear Interpolation
G02 A Circular or Helical Interpolation CW
G03 A Circular or Helical Interpolation CCW
G04 B Dwell
G09 B
Decelerate and Stop (formerly known as Exact Stop)
G10 B Parameter Setting
G17 * C Circular Interpolation Plane Selection XY
G18 C Circular Interpolation Plane Selection ZX
G19 C Circular Interpolation Plane Selection YZ
G20 * K Select Inch Units
G21 K Select Metric Units
G22 O Work envelope on
G23 * O Work envelope off
G28 B Return to Reference Point
G29 B Return from Reference Point
G30 B Return to Secondary Reference Point
G40 * D Cutter Compensation Cancel
G41 D Cutter Compensation Left
G42 D Cutter Compensation Right
G43 E Tool Length Compensation (+)
G43.3 E Tool Length Compensation (+) with Axis Tilt Compensation
G44 E Tool Length Compensation (-)
G49 * E Tool Length Compensation Cancel
G50 * M Scaling/Mirroring Off
G51 M Scaling/Mirroring On
G52 B Offset Local Coordinate System Origin
G53 B Rapid Position in Machine Coordinates
G54 L Select Work Coordinate System #1
G55 L Select Work Coordinate System #2
G56 L Select Work Coordinate System #3
G57 L Select Work Coordinate System #4
G58 L Select Work Coordinate System #5
G59 L Select Work Coordinate System #6
G61 F
Modal Decel and Stop (formerly known as Exact Stop Mode)
G64 * F Smoothing mode selection / Cancel Modal Decelerate and Stop
G65 J Call Macro
G68 N Coordinate Rotation on
G69 * N Coordinate Rotation off
G73 G High Speed Peck Drilling
G74 G Counter Tapping
G76 G Fine Bore Cycle
G80 * G Canned Cycle Cancel
