M-Series Operator’s Manual 4/9/15 15-14
Number Message Cause & Effect Action
946 PC resending The PC is resending Status Message
947 PC received data out
of order
The PC needed to reorder data received
from the MPU
Status Message
948 PC packet error The PC received bad data from the MPU
and will try to recover by requesting a
resend.
Status Message
949 Drive map does not
match hardware
One or more of the drive mapping
parameters 300-307 is misconfigured
Contact Dealer.
Scaling/Mirroring errors
Error Message Cause & Effect Action
1001 Invalid scaling
parameter on line
NNNNN
Invalid parameter specified (I, J, K, P). Job
cancelled.
Remove or change invalid
parameter.
1002 Invalid scaling center
on line NNNNN
Invalid parameter specified (X, Y, Z). Job
cancelled.
Remove or change invalid
parameter.
1003 G-code not allowed
when scaling on line
NNNNN
G28/G29/G30/G92 is not allowed when
scaling or mirroring is turned on. Job
cancelled.
Move G-
line.
1004 Turn scaling off before
rescaling
Tried to rescale while scaling is turned on.
Job cancelled.
Turn scaling off, then
rescale.
1005 Cannot scale arcs with
different scale factors
Scaling factors of the arc axes are different.
Job cancelled.
Correct scaling factors, or
separate scaling operations.
1100-1199
Custom messages defined in cncxmsg.txt. Please contact your dealer if you have any questions
regarding a particular message. This style of message should be replaced with plcmsg.txt format on
MPU11 systems.
Configuration Modification messages
Number Message Cause & Effect
111 ___modified: __ -> __ An axis configuration parameter was modified.
444 __ modified: __ -> __ A servo drive configuration parameter was modified.
555 __ modified: __ -> __ A PID configuration parameter was modified.
556 Axis __ converted: __ -> __ A PID configuration parameter was converted.
777 __ modified: __ -> __ An axis configuration parameter was modified.
888 G30 Z modified: __ -> __ Z coordinate of Secondary Reference Point was modified.
999 Parm #__ modified: __ -> __ A machine parameter was modified.
