Cisco 7931G Administration Guide

8-2
Cisco Unified IP Phone 7931G Administration Guide for Cisco Unified Communications Manager 8.0 (SCCP and SIP)
OL-20798-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Accessing the Web Page for a Phone
Accessing the Web Page for a Phone
To access the web page for a Cisco Unified IP Phone, perform these steps.
Note If you cannot access the web page, it may be disabled. For more information, see Disabling and Enabling
Web Page Access, page 8-3.
Procedure
Step 1 Obtain the IP address of the Cisco Unified IP Phone using one of these methods:
• Search for the phone in Cisco Unified Communications Manager Administration by choosing
Device > Phone. Phones registered with Cisco Unified Communications Manager display the IP
address at the top of the Phone Configuration window.
• On the phone, take either of these actions:
– If the phone is registered with Cisco Unified Communications Manager, press the Application
Menu button, choose Settings > Network Configuration, and then scroll to the IP Address
option.
By default, the Application Menu button is line button 24 (the top left line button).
– If the phone is not registered with Cisco Unified Communications Manager, press the Settings
softkey, choose Network Configuration, and then scroll to the IP Address option.
The Settings softkey appears only when the phone is not registered.
Step 2 Open a web browser and enter the following URL, where IP_address is the IP address of the
Cisco Unified IP Phone:
http://<IP_address> or https://<IP_address>
(depending on the protocol supported by the Cisco Unified IP Phone)
The web page for a Cisco Unified IP Phone 7931G includes these hyperlinks:
• Device Information—Displays device settings and related information for the phone. For more
information, see Device Information, page 8-4.
• Network Configuration—Displays network configuration information and information about other
phone settings. For more information, see Network Configuration, page 8-5.
• Network Statistics—Includes the following hyperlinks, which provide information about network
traffic:
– Ethernet Information—Displays information about Ethernet traffic. For more information,
see Network Statistics, page 8-8.
– Access—Displays information about network traffic to and from the PC port on the phone. For
more information, see Network Statistics, page 8-8.
– Network—Displays information about network traffic to and from the network port on the
phone. For more information, see Network Statistics, page 8-8.

Cisco 7931G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Electromagnetic compatibility	FCC Part 15 (CFR 47) Class B, ICES-003 Class B, EN55022 Class B, CISPR22 Class B, AS/NZS CISPR 22 Class B, CISPR 24, VCCI Class B, EN55024, EN 50082-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1
Wi-Fi	No
Networking standards	IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, TFTP, CDP
Lines quantity	24 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Voice codecs	G.711a, G.729A, G.729B, G.729ab
Volume control	Digital
Display resolution	192 x 64 pixels
Display number of lines	3 lines
Display number of colors	Monochrome
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	(UL) 60950, (CSA) C22.2 No. 60950, EN 60950, IEC 60950, AS/NZS60950, TS 001
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	229 mm
Width	203 mm
Height	178 mm
Weight	1360 g
