Cisco 7931G Administration Guide

9-15
Cisco Unified IP Phone 7931G Administration Guide for Cisco Unified Communications Manager 8.0 (SCCP and SIP)
OL-20798-01
Chapter 9 Troubleshooting and Maintenance
Monitoring the Voice Quality of Calls
Using Voice Quality Metrics
To use the metrics for monitoring voice quality, note the typical scores under normal conditions of zero
packet loss, and use the metrics as a baseline for comparison.
It is important to distinguish significant changes from random changes in metrics. Significant changes
are scores that change about 0.2 MOS or greater and persist in calls that last longer than 30 seconds.
Conceal Ratio changes should indicate greater than 3 percent frame loss.
MOS LQK scores can vary based on the codec that the Cisco Unified IP Phone uses. The following
codecs provide these maximum MOS LQK scores under normal conditions with zero frame loss:
• G.711 codec gives 4.5 score
• G.729A/ AB gives 3.8 score
• G.728/iLBC gives 3.9 score
Note • CVTQ does not support wideband (7 kHz) speech codecs, as ITU has not defined the extension of
the technique to wideband. Therefore, MOS scores that correspond to G.711 performance are
reported for G.722 calls to allow basic quality monitoring, rather than not reporting an MOS score.
• Reporting G.711-scale MOS scores for wideband calls through the use of CVTQ allows basic quality
classifications to be indicated as good/normal or bad/abnormal. Calls with high scores (approximately
4.5) indicate high quality/low packet loss, and lower scores (approximately 3.5) indicate low quality/high
packet loss.
• Unlike MOS, the Conceal Ratio and Concealed Seconds metrics remain valid and useful for both
wideband and narrowband calls.
A Conceal Ratio of zero indicates that the IP network is delivering frames and packets on time with
no loss.
Troubleshooting Tips
When you observe significant and persistent changes to metrics, use Table 9 -4 for general
troubleshooting information.
Table 9-4 Changes to Voice Quality Metrics
Metric Change Condition
MOS LQK scores
decrease significantly
Network impairment from packet loss or high jitter:
• Average MOS LQK decreases could indicate widespread and
uniform impairment.
• Individual MOS LQK decreases indicate bursty impairment.
Cross-check with Conceal Ratio and Conceal Seconds for evidence of packet
loss and jitter.
MOS LQK scores
decrease significantly
• Check to see if the phone is using a different codec than expected (RxType
and TxType).
• Check to see if the MOS LQK version changed after a firmware upgrade.

Cisco 7931G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Electromagnetic compatibility	FCC Part 15 (CFR 47) Class B, ICES-003 Class B, EN55022 Class B, CISPR22 Class B, AS/NZS CISPR 22 Class B, CISPR 24, VCCI Class B, EN55024, EN 50082-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1
Wi-Fi	No
Networking standards	IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, TFTP, CDP
Lines quantity	24 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Voice codecs	G.711a, G.729A, G.729B, G.729ab
Volume control	Digital
Display resolution	192 x 64 pixels
Display number of lines	3 lines
Display number of colors	Monochrome
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	(UL) 60950, (CSA) C22.2 No. 60950, EN 60950, IEC 60950, AS/NZS60950, TS 001
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	229 mm
Width	203 mm
Height	178 mm
Weight	1360 g
