Cisco 7931G Administration Guide

9-4
Cisco Unified IP Phone 7931G Administration Guide for Cisco Unified Communications Manager 8.0 (SCCP and SIP)
OL-20798-01
Chapter 9 Troubleshooting and Maintenance
Resolving Startup Problems
If you are using DHCP, check the IP addresses distributed by your DHCP server. See Understanding
and Troubleshooting DHCP in Catalyst Switch or Enterprise Networks, available at this URL:
http://www.cisco.com/warp/customer/473/100.html#41
Verifying DNS Settings
If you are using DNS to refer to the TFTP server or to Cisco Unified Communications Manager, you
must ensure that you have specified a DNS server. Verify this setting by looking at the DNS Server 1
option on the Settings > Network Configuration menu on the phone. (For information about displaying
this menu, see Displaying a Configuration Menu, page 4-2.) You should also verify that there is a
CNAME entry in the DNS server for the TFTP server and for the Cisco Unified Communications
Manager system.
You must also ensure that DNS is configured to do reverse look-ups.
Verifying Cisco Unified Communications Manager Settings
On the Cisco Unified IP Phone, press the Settings button, choose Device Configuration, and look at the
CM Configuration options. (For information about displaying this menu, see Network Configuration
Menu, page 4-6.) The Cisco Unified IP Phone attempts to open a TCP connection to all the
Cisco Unified Communications Manager servers that are part of the assigned
Cisco Unified Communications Manager group. If none of these options contain IP addresses or show
Active or Standby, the phone is not properly registered with Cisco Unified Communications Manager.
For tips on resolving this problem, see Registering the Phone with Cisco Unified Communications
Manager, page 9-5.
Cisco CallManager and TFTP Services Are Not Running
If the Cisco Unified Communications Manager or TFTP services are not running, phones may not be
able to start up properly. However, in such a situation, it is likely that you are experiencing a system-wide
failure, and other phones and devices are unable to start up properly.
If the Cisco CallManager service is not running, all devices on the network that rely on it to make
phone calls will be affected. If the TFTP service is not running, many devices will not be able to start
up successfully.
Note A service must be activated before it can be started or stopped. To activate a service, choose Tools >
Service Activation.
To start a service, follow these steps:
Procedure
Step 1 From Cisco Unified Communications Manager Administration, choose Cisco Unified Serviceability
from the Navigation drop-down list, and click Go.
Step 2 Choose Tools > Control Center - Network Services.
Step 3 Choose the primary Cisco Unified Communications Manager server from the Server drop-down list.
The window displays the service names for the server that you chose, the status of the services, and a
service control panel to stop or start a service.

Cisco 7931G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Electromagnetic compatibility	FCC Part 15 (CFR 47) Class B, ICES-003 Class B, EN55022 Class B, CISPR22 Class B, AS/NZS CISPR 22 Class B, CISPR 24, VCCI Class B, EN55024, EN 50082-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1
Wi-Fi	No
Networking standards	IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, TFTP, CDP
Lines quantity	24 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Voice codecs	G.711a, G.729A, G.729B, G.729ab
Volume control	Digital
Display resolution	192 x 64 pixels
Display number of lines	3 lines
Display number of colors	Monochrome
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	(UL) 60950, (CSA) C22.2 No. 60950, EN 60950, IEC 60950, AS/NZS60950, TS 001
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	229 mm
Width	203 mm
Height	178 mm
Weight	1360 g
