4-6
Cisco Unified IP Phone 7931G Administration Guide for Cisco Unified Communications Manager 8.0 (SCCP and SIP)
OL-20798-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
Network Configuration Menu
The Network Configuration menu provides options for viewing and making a variety of network
settings. Tables 4-2, 4-3 and 4-4 describe these options and, where applicable, explain how to
change them.
For information about how to access the Network Configuration menu, see Displaying a Configuration
Menu, page 4-2.
Before you can change an option on this menu, you must unlock options as described in Unlocking and
Locking Options, page 4-3. The Edit, Ye s , or No softkeys for changing network configuration options
appear only if options are unlocked.
For information about the keys you can use to edit options, see Editing Values, page 4-4.
Note The phone also has a Network Configuration menu that you access from the Device Configuration menu.
For information about the options on that menu, see Network Configuration Menu, page 4-32.
Table 4-2 Network Configuration Menu Options
Option Description To Change
IPv4 Configuration Internet Protocol v4 address menu. In the IPv4 Configuration menu,
you can do the following:
Enable or disable the phone to use the IPv4 address that is
assigned by the IPv4 DHCP server.
Manually set the IPv4 Address, Subnet Mask, Default Routers,
DNSv4 Server, and Alternate TFTP servers for IPv4.
For more information on the IPv4 address fields, see the specific
fields within this table.
1. Unlock network
configuration options.
2. Scroll to IPv4 Configuration
and press the Select softkey.
IPv6 Configuration Internet Protocol v6 address menu. In the IPv6 Configuration menu,
you can do the following:
Enable or disable the phone to use the IPv6 address that is assign
by the DHCPv6 server or to use the IPv6 address that it acquires
through Stateless Address Autoconfiguration (SLAAC).
Manually set the IPv6 Address, Subnet Prefix Length, Default
Routers, DNSv6 Server, and IPv6 TFTP servers.
For more information on the IPv6 address fields, see Table 4-4.
For more information on SLAAC, see Deploying IPv6 in Unified
Communications Networks with Cisco Unified Communications
Manager 7.1(x).
1. Unlock network
configuration options.
2. Scroll to IPv6 Configuration
and press the Select softkey.
MAC Address Unique Media Access Control (MAC) address of the phone. Display only—Cannot
configure.
Host Name Unique host name that the DHCP server assigned to the phone. Display only—Cannot
configure.
