Cisco Unified IP Phone 7931G Administration Guide for Cisco Unified Communications Manager 8.0 (SCCP and SIP)
OL-20798-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
Network Configuration
The Network Configuration area on a phone’s web page displays network configuration information and
information about other phone settings. Table 8-2 describes this information.
You can view and set many of these items from the Network Configuration Menu and the Device
Configuration Menu on the Cisco Unified IP Phone. For more information, see Chapter 5, “Configuring
Features, Templates, Services, and Users.”
To display the Network Configuration area, access the web page for the phone as described in Accessing
the Web Page for a Phone, page 8-2, and then click the Network Configuration hyperlink.
UDI Displays the following Cisco Unique Device Identifier (UDI) information about
the phone:
• Device Type—Indicates hardware type. For example, phone displays for all
phone models
• Device Description—Displays the name of the phone associated with the
indicated model type
• Product Identifier—Specifies the phone model
• Version Identifier—Represents the hardware version of the phone
The Version Identifier field may display blank if you are using an older
model Cisco Unified IP Phone because the hardware does not provide this
information.
• Serial Number—Displays the phone’s unique serial number
Time Time obtained from the Date/Time Group in Cisco Unified Communications
Manager to which the phone belongs
Time Zone Timezone obtained from the Date/Time Group in Cisco Unified
Communications Manager to which the phone belongs
Date Date obtained from the Date/Time Group in Cisco Unified Communications
Manager to which the phone belongs
Table 8-1 Device Information Area Items (continued)
Item Description
Table 8-2 Network Configuration Area Items
Item Description
DHCP Server IP address of the DHCP server from which the phone obtains its IP address.
BOOTP Server Indicates whether the phone obtains its configuration from a Bootstrap
Protocol (BootP) server.
MAC Address Media Access Control (MAC) address of the phone.
Host Name Host name that the DHCP server assigned to the phone.
Domain Name Name of the DNS domain in which the phone resides.
IP Address IP address of the phone.
Subnet Mask Subnet mask used by the phone.

Cisco 7931G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Electromagnetic compatibility	FCC Part 15 (CFR 47) Class B, ICES-003 Class B, EN55022 Class B, CISPR22 Class B, AS/NZS CISPR 22 Class B, CISPR 24, VCCI Class B, EN55024, EN 50082-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1
Wi-Fi	No
Networking standards	IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, TFTP, CDP
Lines quantity	24 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Voice codecs	G.711a, G.729A, G.729B, G.729ab
Volume control	Digital
Display resolution	192 x 64 pixels
Display number of lines	3 lines
Display number of colors	Monochrome
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	(UL) 60950, (CSA) C22.2 No. 60950, EN 60950, IEC 60950, AS/NZS60950, TS 001
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	229 mm
Width	203 mm
Height	178 mm
Weight	1360 g
