Cisco RV110W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV110W Administration Guide 50
2
STEP 2 Enter the following information to configure the IPv6 LAN address:
STEP 3 Click Save.
Configuring DHCPv6 Settings
To configure IPv6 LAN settings:
STEP 1 Choose Networking > IPv6 > IPv6 LAN Configuration.
STEP 2 Enter the following information to configure the DHCPv6 settings:
IPv6 Address Enter the IPv6 address of the Cisco RV110W.
The default IPv6 address for the gateway is fec0::1
(or FEC0:0000:0000:0000:0000:0000:0000:0001).
You can change this 128-bit IPv6 address based on
your network requirements.
IPv6 Prefix Length Enter the IPv6 prefix length.
The IPv6 network (subnet) is identified by the initial
bits of the address called the prefix. By default, the
prefix is 64 bits long.
All hosts in the network have the identical initial bits
for their IPv6 address; you set the number of
common initial bits in the network addresses in this
field.
DHCP Status Check to enable the DHCPv6 server.
If enabled, the Cisco RV110W assigns an IP
address within the specified range plus additional
specified information to any LAN endpoint that
requests DHCP-served addresses.
Domain Name (Optional) Enter the domain name of the DHCPv6
server.

Cisco RV110W Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input voltage	12 V
Rack mounting	No
Number of users	32 user(s)
Weight (imperial)	0.61 lbs
Dimensions (WxDxH)	150 x 150 x 30 mm
Operating temperature (T-T)	32 - 104 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Supported data transfer rates	10/100Mbps
Dimensions (W x D x H) (imperial)	5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported	11, 54 Mbit/s
Supported network protocols	PPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Firewall security	VPN
Security algorithms	WEP, WPA, WPA2, WPS
MAC address filtering	-
Product color	Black
Certification	FCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
