Cisco RV120W Administration Guide

Configuring Virtual Private Networks (VPNs) and Security
Configuring Advanced VPN Parameters
Cisco RV120W Administration Guide 100
5
STEP 3 In the End Address field, enter the last IP address in the range.
STEP 4 If you chose Subnet as the type, enter the Subnet Mask of the network.
Split DNS
Split DNS allows the Cisco RV120W to find the DNS server of the remote router
without going through the ISP (Internet).
To e n a b l e s p l i t D N S :
STEP 1 Check the Enable box.
STEP 2 In the Domain Name Server 1 field, specify a Domain Name server IP address,
which is used only to resolve the domain configured in the Domain Name 1 field.
STEP 3 In the Domain Name Server 2 field, specify a Domain Name server IP address,
which is used only to resolve the domain configured in the Domain Name 2 field.
STEP 4 In the Domain Name 1 field, specify a domain name, which will be queried only
using the DNS server configured in the Domain Name Server 1 field.
STEP 5 In the Domain Name 2 field, specify a domain name, which will be queried only
using the DNS server configured in the Domain Name Server 2 field.
NOTE Make sure that you avoid using overlapping subnets for remote or local traffic
selectors. Using these subnets would require adding static routes on the router and
the hosts to be used.
For example, a combination to avoid would be:
Local Traffic Selector: 192.168.1.0/24
Remote Traffic Selector: 192.168.0.0/16

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
