Cisco RV120W Administration Guide

Viewing the Cisco RV120W Status
Viewing the Dashboard
Cisco RV120W Administration Guide 137
8
The view of the back panel shows you which ports are used (colored in green) and
allows you to click the port to obtain information about the connection.
• To view a port’s connection information, click the port.
• To refresh the port information, click Refresh.
• To close the port information sheet, click Close.
The Dashboard page displays the following:
Device Information
Resource Utilization
Syslog Summary
Indicates whether logging is enabled for these event categories:
• Emergency
• Alert
• Critical
• Error
• Warning
Host Name The name of the device.
To change the name, click Edit. See Configuring
IPv4 LAN (Local Network) Settings, page 27.
Firmware Version The current software version the device is running.
Serial Number The serial number of the device.
CPU CPU utilization.
Memory Memory utilization.
Current Time Time of day.
System Up Time How long the system has been running.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
