Cisco RV120W Administration Guide

Viewing the Cisco RV120W Status
Viewing the Dashboard
Cisco RV120W Administration Guide 138
8
To view the logs, click details. For more information see Viewing Logs, page 145.
To m a n a g e l o g s , c l i c k manage logging. For more information see Configuring
Logging, page 126.
LAN (Local Network) Interface
To view the LAN settings, click details. For more information see Viewing Port
Statistics, page 148.
WAN (Internet) Information
To view the WAN settings, click details. For more information see Viewing Port
Statistics, page 148.
Wireless Networks
Lists the status of the four wireless network SSIDs
To view the router’s wireless settings, click details. For more information see
Viewing the Wireless Statistics, page 142.
MAC Address The MAC address of the router.
IPv4 Address The local IP address of the router.
To change the IP address, see Configuring the
IPv4 WAN (Internet), page 20.
DHCP Server The status of the router’s DHCP server
(enabled or disabled).
To configure the DHCP settings, see Configuring
the IPv4 WAN (Internet), page 20.
IP Address The IP address of the router’s WAN port.
To change the IP address, see Configuring the
WAN (Internet) Settings, page 19.
State The state of the Internet connection (up or down).

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
