Cisco RV120W Administration Guide

Viewing the Cisco RV120W Status
Viewing the System Summary
Cisco RV120W Administration Guide 140
8
LAN (Local Network) Information
MAC Address The MAC address of the device.
IPv4 Address The IP address and subnet mask of the device.
IPv6 Address The IP address and subnet mask of the device
(shown only if IPv6 is enabled).
DHCP Server The status of the router’s DHCP server
(enabled or disabled). If it is enabled, DHCP client
machines connected to the LAN port receive their
IP address dynamically.
DHCP Relay Whether the device is acting as a DHCP relay.
DHCPv6 Server Whether the device’s DHCPv6 server is enabled or
disabled. If it is enabled, DHCPv6 client systems
connected to the LAN port receive their IP address
dynamically.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
