Cisco RV120W Administration Guide

Configuring the Firewall
Firewall Configuration Examples
Cisco RV120W Administration Guide 90
4
Example 4: Block traffic by schedule if generated from specific range of
machines
In this example, you want to block all HTTP traffic on the weekends if the request
originates from a specific group of machines in the LAN having a known range of
IP addresses, and anyone coming in through the Network from the WAN (i.e. all
remote users).
STEP 1 Setup a schedule. Choose Firewall > Advanced Settings > Schedules.
STEP 2 Click Add.
STEP 3 Enter the schedule name (for example, “Weekend”).
STEP 4 Under Time, check All Day.
STEP 5 Under Repeat, leave Everyday unchecked.
STEP 6 Check Saturday and Sunday.
STEP 7 Click Save.
Create an outbound access rule with the following parameters:
Parameter Value
Connection Type Outbound
Action Block by Schedule
Schedule Weekend
Service HTTP
Source IP Address Range
Start starting IP address
Finish ending IP address
Destination IP Any
Rule Status Enabled

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
