COBHAM GR740 - Page 308

GR740-UM-DS, Nov 2017, Version 1.7 308 www.cobham.com/gaisler
GR740
21.3.2 Interrupt pending register
Table 380.0x004 - IPEND - Interrupt pending register
21.3.3 Interrupt force register
Table 381.0x008 - IFORCE0 - Interrupt force register for processor 0
21.3.4 Interrupt clear register
Table 382.0x00C - ICLEAR - Interrupt clear register
31 16 15 1 0
EIP[31:16] IP[15:1] R
000
rw rw r
31:16 Extended Interrupt Pending n (EIP[n]) - Interrupt pending for interrupt n
15:1 Interrupt Pending n (IP[n]) - Interrupt pending for interrupt n
0 Reserved
31 16 15 1 0
RESERVED IF[15:1] R
000
rrwr
31:16 Reserved
15:1 Interrupt Force n (IF[n]) - Force interrupt nr n.
0 Reserved
31 16 15 1 0
EIC[31:16] IC[15:1] R
0
wwr
31:16 Extended Interrupt Clear n (EIC[n]) - Writing ‘1’ to EIC[n] will clear interrupt n
15:1 Interrupt Clear n (IC[n]) - Writing ‘1’ to IC[n] will clear interrupt n
0 Reserved
