Introduction Control Station Duetto
10 2.0/0518
3 Use of external reference:
External power supplies are used (0 – 24 VDC).
4 The outputs are designed as open drain outputs.
Handset
Connect the handset to the 4P4C jack “handset”. The audio settings can be configured via the web in-
terface (see page 41).
Headset
Connect the headset to the 4P4C jack “headset”. The audio settings can be configured via the web in-
terface (see page 41).
USB 2.0
The DUETTO device has three USB 2.0 ports. The USB ports can be deactivated/activated via the web
interface (
see page 46).
Compatibility SIP PBX
Basically, the DUETTO device can be used with any SIP server. The following SIP server types have
been tested explicitly by Commend and therefore a proper functionality can be confirmed:
NOTE: Cable length
Max. cable length: 2 m
ATTENTION: Suppression diode required at inductive loads
For use of the output with inductive loads, a suppression (flyback) diode must be used in parallel to
the load (otherwise, the output can be damaged)!
Manufacturer
1)
Type Version
Cisco
Cisco Call Manager
Cisco Unified Communication Manager
Version 9.x
3CX 3CX for Windows Version 15.5
Starface Starface free Version 5.8
FreeSWITCH FreeSWITCH Version 1.2.0
1)
The listed products and company names are brand names or registered trademarks of their respective owners.
