Setup guide Control Station Duetto
18 2.0/0518
CCT 800 configuration
Depending on the respective functions to be enabled or used for DUETTO, some of the instructions
may not be relevant and can therefore be skipped.
Add control desk function
DUETTO has the same configuration procedure as a conventional IP station and it is recognised by
CCT
800 as such. For further information about in-depth configuration, see manual “Intercom Server
Configuration“.
Configuration CCT 800
Subscriber > Station Properties > IP terminals > tab Common
Terminal IP Address: In this field, enter the same IP address, which is configured in IP Station
Config or web interface for the DUETTO device.
Port no: In this field, enter the same port number, which is configured in IP Station Config or web
interface for the DUETTO device.
→ By default: 16400
Dynamic registration: Activate this checkbox to enable the dynamic registration. The field MAC
address will be activated.
MAC address: In this field, the MAC address of DUETTO can be entered. The MAC address will be
configured automatically if the checkbox Dynamic registration is deactivated.
Use built-in video camera
CCT 800 detects the built-in video camera of EE 980CM and SIP-EE 980CM automatically as soon as the
device is registered. In contrast with conventional cameras, nearly all settings of the built-in video cam
-
era are configured automatically. For further information about the registration of an external camera,
see manual “Video WS”.
Configuration CCT 800
Subscriber > Station Properties > Cameras > tab Camera
Camera no: In this field, enter a unique number for the built-in video camera.
(Optional) Camera description: In this field, an up to 14-characters-long text can be entered, which
will be used in CCT 800.
(Optional) Camera text: In this field, an up to 14-characters-long camera text can be entered, which
will be displayed on TFT displays
/ monitors during camera connection.
Subscriber > Station Properties > Cameras > tab Addressing
Card IP address: Shows the IP address of the IP subscriber card to which DUETTO is connected.
Terminal IP Address: Shows the IP address of DUETTO.
ATTENTION: Only for Intercom function
This installation step is only required for devices that will be configured as Intercom stations!
ATTENTION: DUETTO must be initialized when changing terminal port
When a new device type is connected to a subscriber Ethernet port in an Intercom system, this device
must be initialized manually in CCT 800. A migration of the device type is not supported. For further
information, see manual “Intercom Server Configuration”.
ATTENTION: Enter unique MAC address
In order to prevent interferences, make sure that an unique MAC address is entered!
ATTENTION: Camera number must not be “0”
The camera number must not be “0”. Otherwise, the video stream is not shown on the DUETTO
display!
