Introduction Control Station Duetto
12 2.0/0518
Supported external USB devices
Chip sets for connection with a Wi-Fi network
The following chip sets have been tested by Commend International GmbH to connect the DUETTO de-
vice to a Wi-Fi network:
RT2800USB
RTL8192CU
RTL8192EU
The DUETTO device can be connected with a Wi-Fi network via the program interface (see page 102).
EB1A – USB output module with one relay output
The USB output module “EB1A” offers a floating, galvanically isolated output contact (normally open
contact) for the DUETTO device, e.g. for use with a door opener. The configuration of the USB output
module is carried out via the web interface.
Technical data EB1A
System requirements
DUETTO device with firmware version 1.4 or higher
Extent of supply
USB output module
Short reference
NOTE: Supported wireless USB adapter
The chip sets RT2800USB, RTL8192CU and RTL8192EU are included in the wireless USB adapters
“TPLinkTLWN823N” and “TPLinkTLW723N”.
NOTE: Consider firmware version
Certain chip sets are not supported on devices running an older firmware version (see page 23).
IP rating: IP20 (acc. EN 60529)
Connection: USB 2.0 (Type A)
max. 20 mA at 5 V
Relay output:
2-pin spring terminal (normally open contact)
max. operation current: 1 A (up to 55 °C/131 °F;
from 55 °C/131 °F, the max. operation current
is reduced by 0.1 A per 10 °C)
max. operation voltage: 20 VAC/30 VDC
insulation voltage: 500 VAC
wire diameter: min. AWG 26, max. AWG 20
(min. Ø 0,4 mm, max. Ø 0,8 mm)
Operating temperature range: –40 °C to +70 °C (–40 °F to +158 °F)
Storage temperature range: –40 °C to +70 °C (–40 °F to +158 °F)
Relative humidity: up to 90%, non-condensing
NOTE: Further information
For further information about the USB output module “EB1A”, see data sheet “EB1A”.
