Introduction Control Station Duetto
6 2.0/0518
Technical specification
Device features
DUETTO “Features”
1 Handset: Remains magnetically in position (handset separately available)
2 Video camera: Only for EE 980CM and SIP-EE 980CM
3 Display: 7” TFT touch screen with IPS (In-Plane Switching)
4 Loudspeaker: For Hi-Fi audio quality up to 20 kHz
5 Gesture control: Wakes DUETTO contact-less from the idle state
6 Microphone array: With digital MEMS microphones
7 Status LED: Red – Intercom call, blue – SIP call, flashing white – missed call, cyan – All Call
Connectors
DUETTO “Connections”
1 USB 2.0 port
2 MicroSD card slot
3 Input / Output: RJ12 jack. An overview of the pin assignment can be found on page 9.
4 External power supply: Coaxial power jack
5 Network: RJ45 jack
6 Headset: 4P4C jack (headset separately available)
7 Handset: 4P4C jack (handset separately available)
8 Service connection (right), reset button (left)
