SNMP – general information
The “Simple Network Management Protocol“ (SNMP) is a network protocol that controls and monitors
network elements (e.g. router, server, switches or SIP stations) from a central management station
. It
controls the communication between the monitored devices and the central management station. Fur
-
thermore, SNMP describes the structure of the data packets and the communication process.
The state of the monitored devices are detected by programs (“agents”) that run directly on the respec-
tive devices. By means of SNMP, the central management station can communicate with these agents
via the network.
OIDs
The device parameters of the DUETTO device, which are read out by the central management station,
are described in a “Management Information Base” (MIB). Consider the following requirements to read
out OIDs:
Supported SNMP version: SNMPv1 or SNMPv2c
Default SNMP port: 161
Community string: “public”
In the following table, the available OIDs to request the device parameters are listed:
Device objects
Input/output objects
Network objects
NOTE: MIB monitoring tool required
In order to display these device parameters, a MIB monitoring tool is required. There are different MIB
monitoring tools that can be downloaded from the Internet.
Object name OID Object type Description
stationType .1.3.6.1.4.1.41836.1.1.1 Octet string bct one terminal
softwareVersion .1.3.6.1.4.1.41836.1.1.3 Octet string Current firmware version
hardwareVersion .1.3.6.1.4.1.41836.1.1.4 Octet string Current hardware version
description .1.3.6.1.4.1.41836.1.1.5 Octet string
Device description (configurable in
web interface)
location .1.3.6.1.4.1.41836.1.1.6 Octet string
Device location (configurable in
web interface)
uptime .1.3.6.1.4.1.41836.1.1.7 TimeTicks Time since last device start
Object name OID Object type Description
din1Status .1.3.6.1.4.1.41836.1.6.1 TruthValue State of the digital input 1
din2Status .1.3.6.1.4.1.41836.1.6.2 TruthValue State of the digital input 2
dout1Status .1.3.6.1.4.1.41836.1.6.3 TruthValue State of the digital output 1
dout2Status .1.3.6.1.4.1.41836.1.6.4 TruthValue State of the digital output 2
addonStatus .1.3.6.1.4.1.41836.1.6.5 TruthValue State of the USB output module EB1A
Object name OID Object type Description
stationIpAddress .1.3.6.1.4.1.41836.1.3.1 IpAddress IP address of the device
stationIp6Address .1.3.6.1.4.1.41836.1.3.2 IpAddress IPv6 address of the device
stationNetmask .1.3.6.1.4.1.41836.1.3.3 IpAddress Subnet mask of the device
gateway .1.3.6.1.4.1.41836.1.3.4 IpAddress IP address of the gateway
gateway6 .1.3.6.1.4.1.41836.1.3.5 InetAddress IPv6 address of the gateway
stationMacAddress .1.3.6.1.4.1.41836.1.3.6 PhysAddress MAC address of the device
