IP Station configuration
Depending on the respective functions to be enabled or used for DUETTO, some of the instructions
may not be relevant and can therefore be skipped. In the following, you will find a detailed step-by-step
setup guide to configure DUETTO as an Intercom station via IP Station Config. For further information
about in-depth configuration see the manuals “GE 300” or “GE 800”.
The program IP Station Config can only be used in local networks (LAN):
 Before DUETTO is installed at the respective location, it has to be configured first in a local network.
 The computer, which is used for configuration, does not have to belong to the same subnet as
DUETTO.
Configuration IP Station Config
 In the header, click on the button Query stations to list all available IP subscribers within the net-
work.
 Color: Click on this button to change the colour as identifier (e.g. to group DUETTO).
 Online: Shows the online state of the DUETTO device (also if the device is not connected to an
Intercom Server).
 (Optional) CallNo: In this field, the call number of the DUETTO device can be entered.
 (Optional) Description: In this field, a description of the DUETTO device can be entered (e.g. the
device text configured in CCT 800).
 Station: Shows the type of the DUETTO device.
 Version: Shows the currently installed version of the DUETTO device.
 IP address: In this field, enter the IP address of the DUETTO device if the function “DHCP” is dis-
abled.
 Subnet mask: In this field, enter the subnet mask of the DUETTO device if the function “DHCP” is
disabled.
 Router-IP: In this field, enter the router IP address of the DUETTO device if the function “DHCP” is
disabled.
 Card-IP: In this field, enter the IP address of the IP card, to which DUETTO is connected.
 Port: In this field, the destination port number of the IP subscriber card can be changed.
→ By default: 16400
 MAC: Shows the MAC address of DUETTO (can be configured via CCT 800 or web interface).
 DYN: Activate this checkbox to enable the dynamic registration.
 DHCP: Activate this checkbox to automatically configure the IP settings via a DHCP server (except
the fields Card-IP and Port).
 (Optional) Host name: In this field, a host name can be entered for the DUETTO device (visible in
the status bar of DUETTO).
 VID: In this field, enter the VLAN ID, which DUETTO will use inside the network.
ATTENTION: Only for Intercom function
This installation step is only required for devices that will be configured as Intercom stations!
NOTE: Configuration of the internal video camera
The internal video camera of the EE 980CM has to be configured in the web interface (see page 43).
NOTE: Update of the device firmware
The device firmware has to be updated in the web interface (see page 14).
