Control Station Duetto Web interface – Customization
2.0/0518 59
Screens editing
DUETTO > CUSTOMIZATION > SCREENS
Move the cursor over the desired screen. Click on a element to configure it (see page 57). The fol-
lowing dialogue appears:
Manage screen > Edit (Full screen)
Add background element: Click on the button Add background element to add a back-
ground element in the virtual screen preview.
Add button: Click on the button Add button to add a button element in the virtual screen pre-
view (see also ”Screens configuration” on page 57).
Hide status bar: (Only for „Full screens“.) Activate this checkbox to hide the upper status bar
of the respective full screen of the DUETTO device.
Do not switch to call interface upon incoming call: Activate this checkbox to prevent an
automatic switch to the call app during an incoming or outgoing call (e.g. when initiating a call
with direct dialling button).
Hide grid: Activate this checkbox to hide the grid in the virtual screen preview.
Click on the desired element in the virtual screen preview to display the control panel.
Create duplicate: Click on the button to duplicate the selected element. The duplicated el-
ement has the same size and configuration as the original.
Delete element: Click on the button to delete the selected element.
➥ Click on the button Save to save the settings.
GOOD TO KNOW: How many elements can be added?
If the status bar is displayed, up to 120 buttons and background elements can be added in full-screen
mode. They are shown in 10 rows with 12 elements each. By hiding the status bar, it is possible to add up
to 144 buttons and background elements (in 12 rows with 12 elements each) per display.
