Danfoss VLT AQUA Drive FC 202 User Manual

Parameter settings
Table 69: Relevant Parameters for Submersible Pump Application
Parameter
Parameter 1-20 Motor Power [kW]/parameter 1-21 Motor Power [HP]
Parameter 1-22 Motor Voltage
Parameter 1-24 Motor Current
Parameter 1-28 Motor Rotation Check
Parameter 1-29 Automatic Motor Adaptation (AMA) = [2] Enable Reduced AMA
Table 70: Example of Settings for Submersible Pump
Parameter Setting
Parameter 3-02 Minimum Reference The minimum reference unit matches the unit in parameter 20-12 Reference/ Feed-
back Unit
Parameter 3-03 Maximum Reference The maximum reference unit matches the unit in parameter 20-12 Reference/ Feed-
back Unit
Parameter 3-84 Initial Ramp Time (2 s)
Parameter 3-88 Final Ramp Time (2 s)
Parameter 3-41 Ramp 1 Ramp Up Time (8 s depending on size)
Parameter 3-42 Ramp 1 Ramp Down Time (8 s depending on size)
Parameter 4-11 Motor Speed Low Limit [RPM] (30 Hz)
Parameter 4-13 Motor Speed High Limit [RPM] (50/60 Hz)
To set up the feedback settings in the PID controller, use the Closed-loop wizard under Quick Menu, Function Set-up.
Table 71: Example of Settings for Pipe-Fill Mode
Parameter Setting
Parameter 29-00 Pipe Fill Enable Disabled
Parameter 29-04 Pipe Fill Rate (Feedback units)
Parameter 29-05 Filled Setpoint (Feedback units)
Wiring Configuration Examples
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
124 | Danfoss A/S © 2018.10
