Danfoss VLT AQUA Drive FC 202 User Manual

e30bu152.10
1
3
2
4
5
1 Input filter cabinet (passive harmonic filter or line reactor)
3 Sine-wave cabinet
5
Input power options
(1)
2 Drives cabinet
4 Control compartment
1
The D9h enclosure does not require an input power options cabinet – the input power options are placed in the drive cabinet.
Illustration 1: Possible Configurations for a D9h Enclosed Drive
e30bu067.10
1
2
4
5
3
1 Input filter cabinet (passive harmonic filter or line reactor)
3 Drive cabinet
5 Control compartment
2
Input power options cabinet
(1)
4 Sine-wave filter cabinet
1
If more than 1 input power option is ordered, the D10h enclosed drive requires an input power options cabinet. Otherwise the single input power option is placed below the control
compartment in the drive cabinet.
Illustration 2: Possible Configurations for a D10h Enclosed Drive
Product Overview
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
14 | Danfoss A/S © 2018.10
