Table 16: LCP Menu Keys
Callout Key Function
B1 Status Shows operational information.
B2 Quick Menu Allows access to parameters for initial set-up instructions. Also provides detailed application steps. Refer
to Quick Menu Mode in the LCP Menu section.
B3 Main Menu Allows access to all parameters. Refer to Main Menu Mode in the LCP Menu section.
B4 Alarm Log Shows a list of current warnings and the last 10 alarms.
C. Navigation keys
Navigation keys are used for programming functions and moving the display cursor. The navigation keys also provide speed control in
local (hand) operation. The display brightness can be adjusted by pressing [Status] and [▵]/[▿] keys.
Table 17: LCP Navigation Keys
Callout Key Function
C1 Back Reverts to the previous step or list in the menu structure.
C2 Cancel Cancels the last change or command as long as the display mode has not changed.
C3 Info Shows a definition of the function being shown.
C4 OK Accesses parameter groups or enables an option.
C5 [▵][▹] [▿] [◃] Moves between items in the menu.
D. Indicator lights
Indicator lights identify the drive status and provides a visual notification of warning or fault conditions.
Table 18: LCP Indicator Lights
Callout Indicator Light Function
D1 On Green Activates when the drive receives power from the mains voltage or a 24 V external supply.
D2 Warn. Yellow Activates when warning conditions are active. Text appears in the display area identifying the
problem.
D3 Alarm Red Activates during a fault condition. Text appears in the display area identifying the problem.
E. Operation keys and reset
The operation keys are found toward the bottom of the local control panel.
Table 19: LCP Operation Keys and Reset
Callout Key Function
E1 [Hand On] Starts the drive in local control. An external stop signal by control input or serial communication overrides
the local [Hand On].
E2 Off Stops the motor but does not remove power to the drive.
E3 Reset Resets the drive manually after a fault has been cleared.
Product Overview
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
28 | Danfoss A/S © 2018.10
