Danfoss VLT AQUA Drive FC 202

Example:
e30bu170.10
1
2
3
4
5
6
1 Cabinet screen (lower)
3 Brake and load share terminals
5 Ground terminals
2 Terminal cover
4 Mains terminals
6 Grounding bar
Illustration 49: Connection Points for Mains to Drive Module
