Example:
e30bu171.10
1
3
4
5
6
2
1 Cabinet screen (lower)
3 Terminal cover
5 Ground terminals on drive module
2 DC terminals
4 Motor terminals
6 Grounding bar
Illustration 52: Connection Points for Drive Module to Motor
Electrical Installation
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
86 | Danfoss A/S © 2018.10
