Datalogic Gryphon 2D Series Product Reference Guide

Reader, Cradle and LEDs Description
Product Reference Guide 17
Reader, Cradle and LEDs Description
LEDs on the gun provide information about the battery charging status as well
as data transmission.
Figure 9- Gryphon Base LEDs
1
2
3
4
5
1 Scan Window 4 Good Read LED
2 Trigger 5 USB Port
3 Battery & Recharge LED
5
6
1
2
3
4
1 Service Button 4 Cable Release Hole
2 Power LED 5 Communicatioin Port
3 Recharge LED 6 Aux Power Port

Datalogic Gryphon 2D Series Specifications

General

Brand	Datalogic
Model	Gryphon 2D Series
Category	Barcode Reader
Language	English
