Setup
30 Gryphon™ I GD/GBT/GM4500
Interface Selection
Upon completing the physical connection between the scanner and its host,
proceed directly to
"Configuring the Interface"
on page 30 for information and
programming for the interface type the scanner is connected to (for example:
RS
-232, Keyboard Wedge, USB, etc.) and scan the appropriate bar code in that
section to select your system’s correct interface type.
The scanner, depending upon the model, will support one of the following sets
o
f host interfaces:
• USB (Keyboard, COM, OEM)
• USB Composite (Keyboard + COM)
• USB HID POS
• USB Toshiba TEC
• RS-232 STD
• RS-232 WN
• RS232 OPOS
• Keyboard Wedge
• IBM46XX port 9b (a spec
ific cable's required)
• Datalogic Magellan Scanne
rs' specific interface
Configuring the Interface
Scan the programming bar code from the following section which selects the
appropriate interface type to match the system the scanner will be connected
to. Next, proceed to the corresponding chapter in this manual (also listed in the
table) to configure any desired settings and features associated with that inter-
face.
NOTE
Unlike some other programming featur
es and options, interface selections require that
you scan only one programming bar code label. DO NOT scan an ENTER/EXIT bar code
prior to scanning an interface selection bar code. Some interfaces require the scanner
to start in the disabled state when powered up. If additional scanner configuration is
desired while in this state, pull the trigger and hold for 5 seconds. The scanner will
change to a state that allows programming with bar codes.
