RS-232 ONLY Interface Enter/Exit Programming Mode
Product Reference Guide 41
RS-232 ONLY Interface
Use the programming bar codes in this chapter if modifications to the standard
RS-232 interface settings are necessary to meet your system’s requirements.
Additional settings which apply to both the RS-232 and USB interfaces are
available in
Chapter 5, RS-232/USB-COM Interfaces.
BAUD RATE on page 41 PARITY on page 43
DATA BITS on page 42 HANDSHAKING CONTROL on page 44
DATA BITS on page 42
RS-232 Standard Factory Settings
Reference Appendix B, for a listing of standard factory settings.
Baud Rate
Baud rate is the number of bits of data transmitted per second. Set the scan-
ner's baud rate to match the baud rate se
tting of the host device. With an
improper baud rate setting, data may not reach the host correctly.
Baud Rate = 1200
Baud Rate = 2400
Baud Rate = 4800
Baud Rate = 9600
$CR2BA00
$CR2BA01
$CR2BA02
$CR2BA03
To Next Page
