Technical Specifications
316 Gryphon™ I GD/GBT/GM4500
Programming Mode
The following indications ONLY occur when the scanner is in Programming Mode.
INDICATION DESCRIPTION LED SPEAKER
Label Program-
ming Mode
Entry
A valid programming label has
been
scanned.
LED blinks continuously
Scanner sounds four low fre-
quency beeps.
Label Program-
ming Mode
R
ejection of
Label
A label has been rejected. N/A
Scanner sounds three times at
l
owest frequency & current
volume.
Label Program-
ming Mode
Acceptance of
Pa
rtial Label
In cases where multiple labels
must be scanned to program
one feature, this indication
acknowledges each portion as
it is successfully scanned.
N/A
Scanner sounds one short
bee
p at highest frequency &
current volume.
Label Program-
ming Mode
Acceptance of
P
rogramming
Configuration option(s) have
been successfully pro-
grammed via labels and the
scanner has exited Program-
ming Mode.
N/A
Scanner sounds one high fre-
quency beep and 4 low fre-
quency beeps followed by
re
set beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned. N/A
Scanner sounds two times at
low fr
equency and current vol-
ume.
Troubleshooting
Problem Possible Cause Possible Solutions
Nothing happens when the scan
button is pulled.
No power to the imager.
Check system power. Ensure power
suppl
y is connected.
Interface or power cables are
lo
ose.
Ensure all cable connections are secure.
LED comes on, but bar code does not
de
code.
Imager not programmed for cor-
rect bar code type.
Ensure imager is programmed to read
the
type of bar code scanned. Refer to
the PRG for more information.
Bar code label is unreadable.
Check the label to ensure it is not
defaced. Try
scanning another bar code
type.
Distance between imager and bar
cod
e is incorrect.
Move imager closer to or further from
the bar code.
Bar code is decoded but not trans-
mitted to the host.
Imager not programmed for the
correct host type.
Scan the appropriate host type bar code.
Refer to the PRG for more information.
