280 Gryphon™ I GD/GBT/GM4500
Disable Character
Specifies the value of the RS-232 host command used to disable the scanner.
ASCII characters or any hex value from 0 to 0xFF can be selected.
NOTE
Setting to previously defined characters such as XON, XOFF, or host com-
mands conflicts with normal operation of these characters. 8-bit data is
n
ot recognized when the option
Data Bits on page 42 has been set as 7
Data Bits.
To set the value:
1. Determine the desired character or value. A setting of 0xFF indicates the
Dis
able Character is not used (not available).
2. Use the
ASCII Chart on page 343 on the inside back cover of this manual to
find the hex equivalent for the desired character/value.
3. Go to
page 53 and scan the ENTER/EXIT PROGRAMMING MODE bar code to
enter Programming Mode.
4. Scan the bar code: SELECT DISA
BLE CHARACTER SETTING on
page 53 .
5. Scan the appropriate two alphanumeric characters from the keypad in
Appendix D, Keypad , that represent the desired character/value determined
above. The second character will cause a two-beep indication.
6. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming
Mode.
This completes the procedure. See the table below for examples of how to set
this feature.
Table 10. Disable Character Setting Examples
STEP ACTION EXAMPLES
1 Desired character/value
‘d’ ‘}’ ‘D’
Disable Command
Not Used
2
Hex equivalent from
ASCII
Chart on page 343
0x64 0x7D 0x44 0xFF
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT DISABLE CHARACTER VALUE SETTING
5
Scan Two Characters From
Appendix D, Keypad
‘6’ and ‘4’ ‘7’ and ‘D’ ‘4’ and ‘4’ ‘F’ and ‘F’
6 Scan ENTER/EXIT PROGRAMMING MODE
