Datalogic Gryphon 2D Series Product Reference Guide

Symbologies
Product Reference Guide 303
Set Length 2
This feature specifies one of the bar code lengths for a given symbology.
Length 2 is the maximum label length if in Variable Length Mode, or the second
fixed length if in Fixed Length Mode.
Reference the
1D Symbologies on page 113 section to view the selectable range
(number of characters) for the symbology being set. A setting of 0
0 specifies to
ignore this length (only one fixed length).
Follow these instructions
to set this feature:
1. Determine the desired character length. Pad the number with leading
zer
oes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc.
2. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Program-
ming Mode.
3. Scan the “Select Length 2 Setting” for the symbology being set.
4. Scan the appropriate two digits from the keypad in
Appendix D, Keypad , that
represent the length setting which was determined in the steps above. You
wil
l hear a two-beep indication after the last character.
NOTE
If you make a mistake before the last
character, scan the CANCEL bar
code to abort and not save the entry string. You can then start again
at the beginning.
5. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming
Mode.
This completes the procedure. See the table below for examples of how to set
this fe
ature.
Table 26. Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (ignore second
length)
07 Characters 52 Characters 74 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘5’ and ‘2’ ‘7’ and ‘4’
5 Scan ENTER/EXIT PROGRAMMING MODE
