Datalogic Gryphon 2D Series Product Reference Guide

DOF - Depth of Field (Typical)
a
a.
13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environ-
mental light, 20°C, label inclination 10°
Symbology SR HD
Code 39
5 mil: 7.0 - 38.0 cm (2.7" - 14.9")
10 mil: 2.2 - 58.0 cm (0.8" - 22.8")
20 mil: FOV lim. - 110 cm (up to
43.3")
3 mil: 5.0 - 15.0 cm
(2.0" - 5.9")
5 mil: 0.5 - 25.0 cm
(0.2" - 9.8")
10 mil: 0.5 - 45.0 cm
(0.2" - 17.7")
EAN13
7.5 mil: 9.0 - 30.0 cm
(3.5" - 11.8")
13 mil: 1.0 - 71.0 cm
(0.4" - 27.9")
7.5 mil: 2.0 - 23.5 cm
(0.8" - 9.2")
13 mil: 1.0 - 40.0 cm
(0.4" - 15.7")
PDF417
6.6 mil: 6.5 - 24.0 cm
(2.6" - 9.4")
10 mil: 2.5 - 41.0 cm
(1.0" - 16.1")
15 mil: 2.3 - 65.0 cm
(0.9" - 25.6")
4 mil: 3.0 - 12.0 cm
(1.2" - 4.7")
6.6 mil: 0.5 - 23.5 cm
(0.2" - 9.2")
10 mil: 0.5 - 31.0 cm
(0.2" - 12.2")
Datamatrix
10 mil: 5.5- 27.0 cm
(2.2" - 10.6")
15 mil: 2.8 - 41.0 cm
(1.1" - 16.1")
5 mil: 5.5 - 9.0 cm
(2.2" - 3.5")
10 mil: 0.2 - 27.0 cm
(0.1" - 10.6")
Max
Resolution
1D Min = 4 mils
PDF417 Min = 5 mils
Datamatrix Min = 7.5 mils
1D Min = 3 mils
PDF417 Min = 3 mils
Datamatrix Min = 4 mils
Product Reference Guide 309
