Replacing the Battery Pack
Product Reference Guide 25
2. Extract the battery pack from its slot.
3. Insert the new battery in the same position.
4. Replace the battery holder cap, plug in the connector and return the con-
tacts circuit to its prev
ious location.
NOTE
When inserting the new battery into the handl
e, take care to position the
battery and the connector as described above.
5. Insert the cover in the handle and screw it into place.
