Using the Gryphon™ I GD/GBT/GM4500
Product Reference Guide 27
A red beam illuminates the label. The field of view indicated by the aiming sys-
tem will be smaller when the reader is closer to the bar code and larger when it
is
farther from the code. Symbologies with smaller bars or elements (mil size)
should be read closer to the unit. Symbologies with larger bars or elements (mil
size) should be read farther from the unit. If the aiming system is centered and
the entire bar code is within the aiming field, you will get a good read. Success-
ful reading is signaled by an audible to
ne plus a good-read green spot LED
indicator.
Relative Size and Location of Green Spot
