98 QuickScan™ Lite QW2400

Pick Mode Timeouts

When the Pick Mode is enabled, it is possible to change the timeouts with which

the Aiming pattern appears/desappears before/after the decoding phase (when

illuminator is on) starts/ends. The longer the timeout the longer the aiming

phase is before and after decoding barcode.

Barcode Timeout before Decoding Phase Timeout after Decoding Phase

Fast

0.5 s

1 s

Medium

1 s 2 s

Slow

2 s 4 s

a. Default
