1D Symbologies Enter/Exit Programming Mode
Product Reference Guide
149
Code 128 Set Length 1
This feature specifies one of the bar code lengths for Code 128 Length Control
on page 148. Length 1 is the minimum label length if in Variable Length on
page 148 Mode, or the first fixed length if in Fixed Length on page 148 Mode.
Length includes the bar code’
s data characters only.
The length can be set from 1 to 80 characters. See "Set Length 1" on page 257
for more detailed programming instructions.
$CC8L1
Select Code 128 Set Length 1 Setting
To configure this feature, scan the ENTER/EXIT bar code
above, then the bar code at left followed by digits from
the Alphanumeric characters in
Appendix D, Key-
pad
representing your desired character(s). End by
scanning the ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort and
not save
the entry string. You can then start again at the
beginning.
~
CANCEL
DEFAULT
01 = Length 1 is 1 Character
To Next Page
