1D Symbologies Enter/Exit Programming Mode

Product Reference Guide

125

Expand EAN 8 to EAN 13

Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13.

EAN 8 2D Component

This feature enables/disables a requirement that a 2D label component be

decoded when a base label for this symbology is decoded.

$C8B3B00

Expand EAN 8 to EAN 13 = Disable

$C8B3B01

Expand EAN 8 to EAN 13 = Enable

DEFAULT

EAN 8 2D Component =

Disable (2D component not required)

EAN 8 2D Component =

2D component must be decoded

DEFAULT

$C8B2D00(CR)

$C8B2D01(CR)
