1D Symbologies Enter/Exit Programming Mode

Product Reference Guide

191

Code 93

The following options apply to the Code 93 symbology.

Code 93 Enable/Disable

Enables/Disables ability of scanner to decode Code 93 labels.

$CC9EN00

Code 93 = Disable

$CC9EN01

Code 93 = Enable

DEFAULT

Default Chapter3
