Datalogic QuickScan Lite QW2400 User Manual

LED and Beeper Indications
Product Reference Guide 267
Programming Mode
The following indications ONLY occur when the scanner is in Programming Mode.
INDICATION DESCRIPTION LED SPEAKER
Label Program-
ming Mode
Entry
A valid programming label has
been scanned.
LED blinks continuously
Scanner sounds four low fre-
quency beeps.
Label Program-
ming Mode
R
ejection of
Label
A label has been rejected. N/A
Scanner sounds three times at
lowe
st frequency & current
volume.
Label Program-
ming Mode
Acceptance of
Pa
rtial Label
In cases where multiple labels
must be scanned
to program
one feature, this indication
acknowledges each portion as
it is successfully scanned.
N/A
Scanner sounds one short
beep at
highest frequency &
current volume.
Label Program-
ming Mode
Acceptance of
Program
ming
Configuration option(s) have
been succes
sfully pro-
grammed via labels and the
scanner
has exited Program-
ming Mode.
N/A
Scanner sounds one high fre-
quency beep and 4 low fre-
quency beeps followed by
re
set beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned. N/A
Scanner sounds two times at
low frequency and current vol-
ume.
