248 QuickScan™ Lite QW2400
Label ID
A Label ID is a customizable code of up to three ASCII characters (each can be
one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It can be
appended previous to or following the transmitted bar code data depending
upon how this option is enabled. This feature provides options for configuring
custom Label IDs as a pre-loaded set or individually per symbology (see
"Label
ID: Set Individually Per Symbology"
on page 73). If you wish to program the scanner
to always include an industry standard label identifier for ALL symbology types,
see
"Global AIM ID"
on page 71.
Label ID: Pre-loaded Sets
The following table lists the pre-loaded label ID sets for the USA and Europe.
Table 12. Label ID Pre-loaded Sets
Symbology USA Label ID set EU Label ID set
ASCII
character
Hex
value
ASCII
character
Hexadecimal
value
ABC Codabar
S 530000 S 530000
CODABAR
% 250000 R 520000
Code 39 CIP
Y 590000 Y 590000
Code 93
& 260000 U 550000
CODE11
CE 434500 b 620000
CODE128
# 230000 T 540000
CODE32
A 410000 X 580000
CODE39
* 2A0000 V 560000
CODE4
4 340000 4 340000
CODE5
j 6A0000 j 6A0000
CODE93
& 260000 U 550000
DATALOGIC 2OF5
s 730000 s 730000
EAN13
F 460000 B 420000
EAN13 P2
F 460000 L 4C0000
EAN13 P5
F 460000 M 4D0000
EAN8
FF 464600 A 410000
EAN8 P2
FF 464600 J 4A0000
EAN8 P5
FF 464600 K 4B0000
FOLLETT 2OF5
O 4F0000 O 4F0000
GS1 DATABAR EXPANDED
RX 525800 t 740000
GS1 DATABAR LIMITED
RL 524C00 v 760000
To Next Page
