1D Symbologies Enter/Exit Programming Mode
Product Reference Guide
189
MSI Set Length 1
This feature specifies one of the bar code lengths for MSI Length Control on
page 188. Length 1 is the minimum
label length if in Variable Length on page
188 Mode, or the first fi
xed length if in Fixed Length on page 188 Mode. Length
includes the bar code’s da
ta characters only.
The length can be set from 01 to 50 characters. See "Set Length 1" on page 257
for more detailed programming instructions.
$CMSL1
Select MSI Set Length 1 Setting
To configure this feature, scan the ENTER/EXIT bar code
above, then the bar code at left followed by digits from
the Alphanumeric characters in
Appendix D, Key-
pad
representing your desired character(s). End by
scanning the ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort and
not save
the entry string. You can then start again at the
beginning.
~
CANCEL
DEFAULT
01 = Length 1 is 1 Character
To Next Page
