Datalogic QuickScan Lite QW2400 User Manual

Keyboard Interface Enter/Exit Programming Mode
Product Reference Guide 61
Keyboard Send Control Characters
This feature is used by the Keyboard Wedge and USB Keyboard interfaces. It
specifies how the scanner transmits ASCII control characters to the host. Refer-
ence Appendix E, Scancode Tables for more information about control charac-
ters.
Options are as follows:
Send Ctrl+Key : ASCII characters from 00H to 0x1FH inclusive are transmitted in
the format Ctrl+Key. Special keys are available in the range from 81H to A1.
Send Ctrl+Shift+Key : The behavior is the same as above, but control keys are sent
in the format Ctrl+Shift+Keys.
Send Special Function Key : Send characters between 00H and 1FH according to
the special function key mapping table (see "In
terface Type PC AT PS/2 Alt
Mode or USB-Keyboard Alt Mode" on page 292). This is used to send keys that
are not in the normal ASCII set. A unique set is provided for each available
scancode set.
$CKBSC00
Keyboard Send Control Characters = Send Ctrl+Key
$CKBSC01
Keyboard Send Control Characters = Send Ctrl+Shift+Key
$CKBSC02
Keyboard Send Control Characters = Send Special Function
Key :
DEFAULT

Datalogic QuickScan Lite QW2400 Specifications

General

IP Rating	IP42
Connectivity	Wired
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Light Source	Red LED
Interface	USB, RS-232
Drop Resistance	1.5 m / 5 ft
Reading Range	Up to 30 cm / 11.8 in (depending on barcode density)
Dimensions	6.7 x 2.8 x 2.6 in
Print Contrast Ratio	25%
Decode Capability	1D, 2D codes
Resolution	4 mils
Depth of Field	5 - 30 cm (depending on barcode density and type)
Power Supply	5 VDC
Humidity	5 to 95% (Non-condensing)
