Datalogic QuickScan Lite QW2400 User Manual

Enter/Exit Programming Mode
18 QuickScan™ Lite QW2400
To program features:
1. Scan the ENTER/EXIT PROGRAMMING bar code, available at the top of each
programming page, when applicable.
2. Scan the bar code to set the desire
d programming feature. You may need
to cover unused bar codes on the page, and possibly the facing page, to
ensure that the scanner reads only the bar code you intend to scan.
3. If additional input parameters ar
e needed, go to Appendix D, Keypad , and
scan the appropriate characters from the keypad.
4. Complete the programming sequence
by scanning the ENTER/EXIT PRO-
GRAMMING bar code to ex
it Programming Mode.
For more detailed descriptions, programming information an
d examples for
setting selected configuration items, see
References, starting on page 233 .
NOTE
Additional information about many features can be found in the “Ref-
erences” chapter.
If you make a mistake before the last character, scan the CANCEL bar
code to ab
ort and not save the entry string. You can then start again at
the beginning.

Datalogic QuickScan Lite QW2400 Specifications

General

IP Rating	IP42
Connectivity	Wired
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Light Source	Red LED
Interface	USB, RS-232
Drop Resistance	1.5 m / 5 ft
Reading Range	Up to 30 cm / 11.8 in (depending on barcode density)
Dimensions	6.7 x 2.8 x 2.6 in
Print Contrast Ratio	25%
Decode Capability	1D, 2D codes
Resolution	4 mils
Depth of Field	5 - 30 cm (depending on barcode density and type)
Power Supply	5 VDC
Humidity	5 to 95% (Non-condensing)
